ПЛОЧКА С БОБИНИ ЗА МАГНЕТ / СТАТОР / ЗА ЯМАХА MAJESTY 250 / YP250 / ЛИНХАЙ / АТВ 250-300 /18 БОБИНИ 5 КАБЕЛА/ Ф104мм |
|||
|
|||
Stator assy (18 poles 5 cables) 104mm:
This an 18 pole, 18 coils, Generator Magneto for the 3 phase 4 stroke liquid cooled Yamaha YP250 LH170MN Linhai VOG 250-300cc engine. Applicable to: YAMAHA: Yamaha Majesty YP250 250cc (2002- ) MBK: MBK Skyliner 250cc Works with Yamaha YP250 LH170MN Linhai LH250, LH260, LH300, LH400, VOG 250-300cc engine. Before 2002, the YP250 engine use 93mm stator coil, after that all YP250 engine use stator 104mm. Overall diameter: 104mm Center inner diameter: 42mm Mounting Bolts Spacing: 47mm (center to center) Stator: 18 coils Plugs: 3 pin + 2 pin Произход: Китай Доставно тегло: 0,820 кг |
|||
