СКУТЕР ПЛОЧКА С БОБИНИ ЗА МАГНЕТ / СТАТОР / GY6-50/70/80 (8 БОБИНИ, 4 КАБЕЛА) Ф88мм / БАОТИАН / КИМКО / СИМ

Chinese SCOOTER - Stator Ø88mm (8 coils, 4 cables) 4T GY6-50/70/80cc 139E1006-2-2P
Order No.: ZD20012B
8 coil stator magneto commonly used on 4-stroke 50cc, 125cc and 150cc GY6 scooter engines. Also sometimes referred to as a stator comp.
Overall diameter: 88mm
Center inner diameter: 29mm
Mounting Bolts Spacing: 41mm (center to center)
4 wires: Yellow, White end in a 3 pin female plug, Red, Blue in single pin.
Mechanics Note : 8 pole stator will work on any GY6 50cc 139QMB (and many others like 2-strokes) as long as you have a matching 8 pole flywheel rotor to go with it and have 4/5 wires. When you order a stator generator, be sure it matches the number of poles your rotor was made for. And in reverse, if you order a flywheel rotor, be sure it matches the number of poles on your stator. If you need both, order a matching 8 pole stator generator and flywheel rotor. These can come either AC or DC so be sure it fits your engines electrical system.
Applicable to:
139QMB KINROAD XT50QT-2
KYMCO AGILITY
SYM ORBIT
BAOTIAN (139 QMB)
